Part Number | Wheel Size | Bolt Circle | Offset (mm) | Back Spacing | Hub Bore (mm) | Load Rating | Cap | Lip Width |
---|---|---|---|---|---|---|---|---|
F72P1-2227351L | 22X12 | 5X5.00 | -51 | 4.49 | 71.5 | 2500 | CAP-FG-GF | 6.39 |
F72P1-2227351R | 22X12 | 5X5.00 | -51 | 4.49 | 71.5 | 2500 | CAP-FG-GF | 6.39 |
F72P1-2228551L | 22X12 | 5X5.50 | -51 | 4.49 | 78 | 2500 | CAP-FG-5-GF | 6.39 |
F72P1-2228551R | 22X12 | 5X5.50 | -51 | 4.49 | 78 | 2500 | CAP-FG-5-GF | 6.39 |
F72P1-2225051L | 22X12 | 5X150 | -51 | 4.49 | 110 | 2500 | CAP-FG-5-GF | 6.39 |
F72P1-2225051R | 22X12 | 5X150 | -51 | 4.49 | 110 | 2500 | CAP-FG-5-GF | 6.39 |
F72P1-2226351L | 22X12 | 6X135 | -51 | 4.49 | 87 | 2500 | CAP-FG-6-GF | 6.39 |
F72P1-2226351R | 22X12 | 6X135 | -51 | 4.49 | 87 | 2500 | CAP-FG-6-GF | 6.39 |
F72P1-2228451L | 22X12 | 6X5.50 | -51 | 4.49 | 108 | 2500 | CAP-FG-6-GF | 6.39 |
F72P1-2228451R | 22X12 | 6X5.50 | -51 | 4.49 | 108 | 2500 | CAP-FG-6-GF | 6.39 |
F72P1-2228151L | 22X12 | 8X6.50 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72P1-2228151R | 22X12 | 8X6.50 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72P1-2228751L | 22X12 | 8X170 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72P1-2228751R | 22X12 | 8X170 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72P1-2228951L | 22X12 | 8X180 | -51 | 4.49 | 124.3 | 3500 | CAP-FG-8-GF | 6.39 |
F72P1-2228951R | 22X12 | 8X180 | -51 | 4.49 | 124.3 | 3500 | CAP-FG-8-GF | 6.39 |
F72P1-2247376L | 22X14 | 5X5.00 | -76 | 4.51 | 71.5 | 2500 | CAP-FG-GF | 8.38 |
F72P1-2247376R | 22X14 | 5X5.00 | -76 | 4.51 | 71.5 | 2500 | CAP-FG-GF | 8.38 |
F72P1-2248576L | 22X14 | 5X5.50 | -76 | 4.51 | 78 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2248576R | 22X14 | 5X5.50 | -76 | 4.51 | 78 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2245076L | 22X14 | 5X150 | -76 | 4.51 | 110 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2245076R | 22X14 | 5X150 | -76 | 4.51 | 110 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2246376L | 22X14 | 6X135 | -76 | 4.51 | 87 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2246376R | 22X14 | 6X135 | -76 | 4.51 | 87 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2248476L | 22X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2248476R | 22X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2248176L | 22X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2248176R | 22X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2248776L | 22X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2248776R | 22X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2248976L | 22X14 | 8X180 | -76 | 4.51 | 124.3 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2248976R | 22X14 | 8X180 | -76 | 4.51 | 124.3 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2447376L | 24X14 | 5X5.00 | -76 | 4.51 | 71.5 | 2500 | CAP-FG-GF | 8.38 |
F72P1-2447376R | 24X14 | 5X5.00 | -76 | 4.51 | 71.5 | 2500 | CAP-FG-GF | 8.38 |
F72P1-2448576L | 24X14 | 5X5.50 | -76 | 4.51 | 78 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2448576R | 24X14 | 5X5.50 | -76 | 4.51 | 78 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2445076L | 24X14 | 5X150 | -76 | 4.51 | 110 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2445076R | 24X14 | 5X150 | -76 | 4.51 | 110 | 2500 | CAP-FG-5-GF | 8.38 |
F72P1-2446376L | 24X14 | 6X135 | -76 | 4.51 | 87 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2446376R | 24X14 | 6X135 | -76 | 4.51 | 87 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2448476L | 24X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2448476R | 24X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72P1-2448176L | 24X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2448176R | 24X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2448776L | 24X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2448776R | 24X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2448976L | 24X14 | 8X180 | -76 | 4.51 | 124.3 | 3500 | CAP-FG-8-GF | 8.38 |
F72P1-2448976R | 24X14 | 8X180 | -76 | 4.51 | 124.3 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2227351L | 22X12 | 5X5.00 | -51 | 4.49 | 71.5 | 2500 | CAP-FG-GF | 6.39 |
F72BM1-2227351R | 22X12 | 5X5.00 | -51 | 4.49 | 71.5 | 2500 | CAP-FG-GF | 6.39 |
F72BM1-2228451L | 22X12 | 6X5.50 | -51 | 4.49 | 108 | 2500 | CAP-FG-6-GF | 6.39 |
F72BM1-2228451R | 22X12 | 6X5.50 | -51 | 4.49 | 108 | 2500 | CAP-FG-6-GF | 6.39 |
F72BM1-2228151L | 22X12 | 8X6.50 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72BM1-2228151R | 22X12 | 8X6.50 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72BM1-2228751L | 22X12 | 8X170 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72BM1-2228751R | 22X12 | 8X170 | -51 | 4.49 | 125.2 | 3500 | CAP-FG-8-GF | 6.39 |
F72BM1-2248476L | 22X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72BM1-2248476R | 22X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72BM1-2248176L | 22X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2248176R | 22X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2248776L | 22X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2248776R | 22X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2448476L | 24X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72BM1-2448476R | 24X14 | 6X5.50 | -76 | 4.51 | 108 | 2500 | CAP-FG-6-GF | 8.38 |
F72BM1-2448176L | 24X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2448176R | 24X14 | 8X6.50 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2448776L | 24X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
F72BM1-2448776R | 24X14 | 8X170 | -76 | 4.51 | 125.2 | 3500 | CAP-FG-8-GF | 8.38 |
